Pre-Owned 2023 Honda CMX500A2 Rebel FOP (ABS) – 471cc Modern Cruiser Motorcycle
The 2023 Honda CMX500A2 Rebel FOP (ABS) is a stylish mid-size cruiser that combines classic bobber looks with modern performance and everyday usability. Powered by a 471cc liquid-cooled parallel-twin engine, the Rebel delivers smooth, responsive power and excellent fuel efficiency—ideal for both city riding and open road cruising.
Designed with easy-going ergonomics and a low seat height, the CMX500A2 is confident and comfortable for riders of varying experience levels. The Advanced ABS braking system enhances safety by providing controlled stopping power in diverse conditions, while its minimalist yet muscular styling gives it standout curb appeal.
- Engine & Drivetrain
- Engine Type 471 cc Liquid-Cooled Parallel-Twin, DOHC, 8-Valve
- Displacement 471 cc
- Bore x Stroke 67.0 mm x 66.8 mm
- Compression Ratio 10.7 : 1
- Fuel System Programmed Fuel Injection (PGM-FI); 34 mm throttle body
- Ignition Full Transistorized Ignition
- Transmission 6-Speed Manual with Assist/Slipper Clutch
- Final Drive O-Ring Sealed Chain
- Suspension & Brakes
- Front Suspension 41 mm Telescopic Fork; ~5.5 in (140 mm) Travel
- Rear Suspension Showa® Twin Shocks; ~3.7 in (95 mm) Travel
- Front Brakes Single 296 mm Disc with ABS
- Rear Brakes Single 240 mm Disc with ABS
- Tires & Wheels
- Front Tire 130/90-16
- Rear Tire 150/80-16
- Wheels Cast Alloy Wheels
- Dimensions & Capacities
- Overall Length 86.8 in (2,205 mm)
- Overall Width 32.3 in (820 mm)
- Overall Height 43.0 in (1,090 mm)
- Wheelbase 58.7 in (1,490 mm)
- Seat Height 27.2 in (690 mm)
- Ground Clearance 5.4 in (136 mm)
- Fuel Capacity 3.0 gal (11.3 L)
- Curb Weight ~417 lb (189 kg) Ready to Ride
- Performance
- Maximum Power ~34 kW (45.6 bhp) @ 8,500 rpm
- Maximum Torque ~43.3 Nm @ 6,000 rpm
- Features & Equipment
- ABS Two-Channel ABS Standard
- Assist/Slipper Clutch Standard
- Instrument Panel Digital LCD Display
