Pre-Owned 2025 Honda TRX420FM1 FourTrax Rancher 4×4 – Rugged, Reliable
The 2025 Honda TRX420FM1 FourTrax Rancher (4×4) is engineered for riders who need strength, durability, and dependable power in every ride. Equipped with a 420cc fuel-injected engine, manual foot-shift transmission, and true 4×4 capability, this ATV handles challenging terrain with ease—whether you’re working on the farm, hitting the trails, or exploring the outdoors.
Honda’s legendary reliability shines through with its rugged frame, smooth suspension, and low-maintenance design. The Rancher’s comfortable seating, strong towing capability, and durable cargo racks make it the perfect blend of workhorse utility and recreational fun.
Built to perform year after year, the 2025 FourTrax Rancher is your go-to machine for toughness, efficiency, and all-terrain versatility.
- Engine & Drivetrain
- Engine Type Liquid-Cooled OHV Longitudinal Single Cylinder 4-Stroke
- Displacement 420cc
- Bore x Stroke 86.5 mm x 71.5 mm
- Fuel System PGM-FI Electronic Fuel Injection (34mm Throttle Body)
- Ignition Full-Transistorised with Electronic Advance
- Starter Electric with Auxiliary Recoil
- Transmission Manual 5-Speed with Reverse
- Drive System Direct Front & Rear Driveshafts with Torque-Sensing Differential (Selectable 2WD/4WD)
- Suspension & Brakes
- Front Suspension Independent Double Wishbone with 170 mm Travel
- Rear Suspension Swing Arm with Single Shock; 170 mm Travel
- Front Brakes Dual Hydraulic 190 mm Discs
- Rear Brakes 160 mm Sealed Mechanical Drum
- Tires & Wheels
- Front Tires 24 x 8-12
- Rear Tires 24 x 10-11
- Dimensions & Capacities
- Overall Length 82.8 in (2103 mm)
- Overall Width 47.4 in (1204 mm)
- Overall Height 46.2 in (1174 mm)
- Wheelbase 50.0 in (1270 mm)
- Seat Height 33.6 in (854 mm)
- Ground Clearance 7.1 in (181 mm)
- Fuel Capacity 3.9 gal (14.7 L) including reserve
- Curb Weight 615 lb (279 kg)
- Payload & Towing
- Front Rack Capacity 66 lb (30 kg)
- Rear Rack Capacity 133 lb (60 kg)
- Towing Capacity 848 lb (385 kg)
- Hitch Type Standard Receiver
