2025 Honda FourTrax Rancher 4x4 – 420cc Liquid-Cooled Utility ATV
The 2025 Honda FourTrax Rancher 4x4 is a rugged, reliable utility ATV built to handle work, trails or farm duty. Powered by a 420cc liquid-cooled, single-cylinder four-stroke engine with PGM-FI fuel injection and a 5-speed manual transmission (plus reverse), it delivers strong performance with low maintenance. Its independent double-wishbone front suspension and swing-arm rear suspension ensure stable handling over rough terrain, while selectable 2WD/4WD with a torque-sensitive locking front differential gives you control and traction where you need it. With a front rack capacity of 66 lbs, rear rack capacity of 133 lbs and a compact, maneuverable design, the Rancher is equally at home on the farm, in the woods or around the property.
- Engine & Drivetrain
- Engine Type 420 cc Liquid‑Cooled Longitudinally Mounted Single‑Cylinder Four‑Stroke
- Bore x Stroke 86.5 mm × 71.5 mm
- Compression Ratio 9.9 : 1
- Induction Programmed Fuel Injection (PGM‑FI) with 34 mm Throttle Body
- Starter Electric with Optional Auxiliary Recoil
- Clutch Automatic Centrifugal
- Transmission Five‑Speed Manual with Reverse
- Driveline Direct Front and Rear Driveshafts with TraxLok® & Torque‑Sensitive Locking Front Differential
- Suspension & Brakes
- Front Suspension Independent Double‑Wishbone; 6.7″ Travel
- Rear Suspension Swingarm with Single Shock; 6.7″ Travel
- Front Brakes Dual 190 mm Hydraulic Discs
- Rear Brake 160 mm Sealed Mechanical Drum
- Tires & Wheels
- Front Tire 24 × 8‑12
- Rear Tire 24 × 10‑11
- Dimensions & Capacities
- Overall Length 82.8″
- Overall Width 47.4″
- Overall Height 46.2″
- Wheelbase 50.0″
- Seat Height 33.6″
- Ground Clearance 7.1″
- Fuel Capacity 3.9 gal (Incl. 1.3 gal Reserve)
- Curb Weight ~615 lb (with Standard Equipment & Fluids)
- Utility & Cargo
- Front Rack Capacity 66 lb
- Rear Rack Capacity 133 lb
- Towing Capacity ~850 lb
- Features & Equipment
- Recommended Age 16 Years & Older
- Emissions EPA & CARB Off‑Road Standards
