NEW AODES PathCross 1000 L – 976cc V-Twin 4x4 Utility ATV
The AODES PathCross 1000 L is a powerful full-size 4x4 utility ATV designed for demanding off-road work, recreation, and adventure riding. Powered by a strong 976cc V-twin 4-stroke liquid-cooled engine, it delivers approximately 85–86 horsepower and high torque output for confident performance on mud, hills, trails, and heavy-duty terrain.
Built with a rugged chassis and advanced drivetrain, the PathCross 1000 L features a selectable 2WD/4WD system with differential lock, allowing riders to adapt traction based on terrain conditions. The automatic CVT transmission ensures smooth acceleration and easy operation without manual shifting.
For off-road control and comfort, it uses an independent double A-arm suspension system with long travel shocks, providing excellent shock absorption on rough terrain. Combined with a high ground clearance of around 10 inches, it is capable of handling deep ruts, rocks, and uneven trails with stability.
- Engine & Drivetrain
- Engine Type 976cc V-Twin, DOHC, Liquid-Cooled, 4-Stroke
- Displacement 976cc
- Cooling Liquid-Cooled
- Fuel System DELPHI Electronic Fuel Injection (EFI)
- Compression Ratio 10.5:1
- Maximum Power 85.4 HP @ 6,500 RPM
- Maximum Torque 74.5 lb-ft (101 Nm) @ 5,500 RPM
- Transmission CVTech Automatic CVT (H/L/N/R/P)
- Drive System Selectable 2WD / 4WD / 4WD Lock with Front Locking Differential
- Final Drive Shaft Drive
- Power Steering 3-Mode Electronic Power Steering (EPS)
- Suspension & Brakes
- Front Suspension Independent Dual A-Arm with Adjustable Gas Coilover Shocks
- Rear Suspension Independent Dual A-Arm with Adjustable Gas Coilover Shocks
- Shock Adjustment 18-Way Adjustable Rebound & Compression
- Front Brakes Dual Hydraulic Ventilated Disc Brakes
- Rear Brakes Dual Hydraulic Ventilated Disc Brakes
- Parking Brake Handlebar-Mounted Parking Brake
- Tires & Wheels
- Front Tires 26 x 9-R14
- Rear Tires 26 x 11-R14
- Wheels 14-inch Aluminum Alloy Wheels
- Dimensions & Capacities
- Overall Length 96.5 in (2450 mm)
- Overall Width 49.0 in (1246 mm)
- Overall Height 55.0 in (1400 mm)
- Wheelbase 59.0 in (1508 mm)
- Ground Clearance 11.2 in (285 mm)
- Fuel Capacity 5.8 gal (22 L)
- Curb Weight 1,053 lb (478 kg)
- Gross Vehicle Weight Rating 1,521 lb (690 kg)
- Payload & Utility
- Front Rack Capacity 75 lb (34 kg)
- Rear Rack Capacity 150 lb (68 kg)
- Towing Capacity 873 lb (396 kg)
- Winch 3,500 lb Front-Mounted Winch
- Passenger Capacity 2 Persons
- Hitch Trailer Ball Hitch Included
- Electronics & Features
- Display Multifunction Digital Touchscreen Display
- Lighting LED Headlights, DRLs and LED Taillights
- Differential Lock Selectable Front Differential Lock
- Protection Front & Rear Bumpers, Handguards, Fender Flares
- USB Power Port Standard USB & 12V Outlet
- Category 2-Up Utility / Recreation ATV
